Chauvet Pro LOGICDRIVE2X - Dual-Output Power over Ethernet Lighting Controller

Dual-Port POE Controller for Remote Lighting Fixtures
The Chauvet Pro LOGIC Drive 2X is a dual-output Power over Ethernet (POE) lighting controller designed to deliver both power and control to compatible remote fixtures. Built for architectural and performance environments, this unit supports the latest IEEE 802.3bt POE standard, enabling power and data transmission through a single cable. Whether you're installing lighting in theaters, lobbies, museums, or public spaces, the Drive 2X streamlines infrastructure and supports multiple protocols for versatile control.

Supports DMX, Art-Net, sACN, and Wall-Based Control
The Drive 2X offers broad compatibility with standard lighting control methods, including DMX via 5-pin XLR, Art-Net, and sACN. It also includes one Chauvet LOGIC Wall Con controller, which enables users to recall up to eight pre-recorded scenes directly from the wall. For larger installations, up to four Wall Cons can be connected to the same Drive 2X, allowing control points in multiple rooms or zones.

Dual High-Power POE Outputs for Fixture Connectivity
Each of the Drive 2X's two POE ports supports up to 110W of output, with a recommended maximum of 92.5W per port for stable operation. This makes it ideal for powering LED downlights, cove lights, or other Chauvet Logic fixtures without requiring separate power runs. This simplification improves installation speed while maintaining professional-grade reliability.

Integrated Webserver for Scheduling and Configuration
The onboard web interface allows integrators and technicians to configure the unit’s network settings, adjust time and date parameters, and create schedules using the built-in calendar and daily trigger functions. These capabilities make the Drive 2X ideal for venues needing time-based lighting automation for preset scenes, environmental control, or energy management.

Occupancy Sensor Integration and Hot-Swapping Support
Designed for smart environments, the Drive 2X supports occupancy sensor inputs that allow dynamic lighting responses based on room usage. It also enables hot-swapping of fixtures with automatic detection, making maintenance or replacements faster and less disruptive. System monitoring for current and voltage is included to ensure electrical safety and performance over time.

RDM Compatibility and System Feedback for Installers
For installers, the unit is fully RDM compliant, enabling remote device management such as status reporting, fault detection, and addressing. This streamlines commissioning and post-installation support for venues where accessibility to individual fixtures may be limited.
