Dielectric 11000000077 - FM ANTENNA DCRT4B5XOS 104.7 MHZ

Enhance Broadcast Quality with Dielectric 11000000077 - FM ANTENNA DCRT4B5XOS 104.7 MHZ
The Dielectric 11000000077, part of the acclaimed DCR-T series, is a state-of-the-art FM antenna specifically designed for low-power applications. This model, optimized for 104.7 MHz, inherits the high-performance attributes of Dielectric’s popular DCR Series but is tailored for smaller-scale operations such as Class A and B stations. With its circular polarization and band tunability, this antenna offers superior coverage and signal quality, making it a top choice for broadcasters aiming to enhance their transmission clarity and range.

Advanced Features for Optimal Transmission
Dielectric's DCR-T antenna boasts a plethora of advanced features engineered to meet the rigorous demands of modern broadcasting. Circular polarization ensures consistent signal dispersion, crucial for reaching your audience without degradation regardless of their location. The antenna's low Voltage Standing Wave Ratio (VSWR) of less than 1.1:1 over the operating channel ensures minimal signal loss, contributing to its efficient performance. Additionally, its capability to handle up to 1 kW per bay power amplifies its suitability for a range of broadcasting needs.

Designed for Durability and Easy Installation
Crafted from all-aluminum, the DCR-T antenna is not only lightweight but also remarkably durable, designed to withstand diverse environmental conditions. Its easy installation process is a significant advantage, allowing broadcast engineers to set up quickly without extensive downtime. The antenna's design also supports null fill and beam tilt adjustments, providing broadcasters with enhanced control over transmission characteristics to suit specific geographical and regulatory requirements.

Flexible Configuration Options
This model is available in various configurations, including 4-bay setups that can be either full-wave or half-wave spaced, depending on the broadcaster's specific coverage needs. Each configuration is designed to optimize the antenna’s performance in different broadcasting environments. Optional features such as radomes are available for broadcasters who require additional protection against environmental elements, ensuring long-term reliability and performance.

Technical Specifications and Adaptability
The Dielectric 11000000077 operates within the FM band range of 88-108 MHz and can be tuned to cater to a wide range of frequencies within this spectrum, making it incredibly versatile. It offers different mounting options, including top and side mounts, which adapt easily to various tower configurations. The antenna's power rating and input specifications accommodate standard broadcasting equipment, making this model a plug-and-play solution for upgrading existing systems.
