Home FM Dielectric DCR-T2BX 2 Bay DCR-T Series Low Power Female Input Antenna
$4,350.00

Compact 2 kW Two-Bay FM Antenna, Circular Polarization, Band Tunable, 12-Foot Design, Enhanced Signal Control, Ideal for Targeted and Efficient Broadcasting

Availability: Special Order, Please Allow 2-4 Weeks For Delivery
SKU
DCR-T2BX

Features:

  • Circular polarization for reduced interference and clearer signal
  • Band tunable for flexible frequency adjustments
  • Low VSWR (<1.1:1) ensures efficient signal transmission
  • 1 kW power handling per bay suitable for low-power stations
  • Lightweight and easy installation with all-aluminum construction
  • Optional null fill and beam tilt for targeted broadcasting
  • Supports configurations from 1 to 6 bays, with full- or half-wave spacing
  • Optional radome for environmental protection
  • Directional patterns available for focused broadcasting

Revolutionize Your Broadcasting with Dielectric DCR-T2BX Antenna
Introducing the Dielectric DCR-T2BX, a state-of-the-art two-bay antenna from the DCR-T Series, specifically designed for low-power FM broadcasting. This antenna combines advanced features such as circular polarization and band tunability, making it a perfect fit for Class A and B stations looking to deliver clear and reliable signals. Ideal for environments where broadcast integrity is paramount, the DCR-T2BX ensures your broadcasts are heard loud and clear without interference.

Optimized Performance for Clear Transmission
The DCR-T2BX is meticulously engineered to support 1 kW per bay, maintaining a low VSWR of less than 1.1:1 across its operating channel. This capability ensures minimal signal loss and superior broadcast quality, even in the most challenging conditions. With band tunability, stations have the flexibility to adjust their frequency settings to optimize broadcast performance, essential for maintaining compliance and maximizing reach.

Lightweight Design for Seamless Installation
Weighing significantly less due to its all-aluminum construction, the DCR-T2BX is not only easy to handle but also simple to install. This lightweight design allows for quick and efficient setups, making it an excellent choice for stations that need a reliable antenna solution that can be deployed rapidly.

Customizable Features to Enhance Broadcasts
The DCR-T2BX offers additional features such as null fill and beam tilt, providing stations with the ability to fine-tune their broadcasting pattern to suit specific geographic needs. Whether improving signal penetration in hilly areas or focusing the broadcast in a particular direction, these features allow for a highly customized approach to FM broadcasting.

More Information
MPN DCR-T2BX
Color Silver
Brand Dielectric
Product Condition New
Availability Out of Stock
