DIELECTRIC FT3T14I- FM Meduim/High Power Bandpass Filter
$12,500.00
Maximize your FM broadcast clarity and power with the DIELECTRIC FT3T14I Bandpass Filter. Tailored for medium/high power applications, it supports up to 16kW with a 3-pole design
Availability:
Special Order, Please Allow 2-4 Weeks For Delivery
SKU
FT3T14I
Features:
- Crafted from AL, CU, and Invar Rod for durability
- Handles ≤16kW, extendable to ≤20kW with blowers
- Operates within 88 - 108 MHz with ≥2.8 MHz channel spacing
- Boasts ≤0.20dB insertion loss and ≥30.7 dB return loss
- Includes EIA 1-5/8", EIA 3-1/8", and EIA 6-1/8" connectors for easy integration
Innovative Filtering Solution
Discover the Dielectric FT3T14I, a cutting-edge FM medium/high power bandpass filter designed for superior broadcasting performance. With a robust design to handle up to 16kW of average power and up to 20kW with blowers, this filter ensures your signals are clear and strong.
Optimized Frequency Range
Engineered for the 88 - 108 MHz frequency range with a 3-pole reflective (bandpass) configuration, it offers precise channel spacing of ≥2.8 MHz. This makes it an ideal choice for FM/FM-HD applications, ensuring your broadcast is delivered with unmatched clarity.
Unparalleled Design
Constructed from high-quality materials including AL, CU, and Invar Rod, the Dielectric FT3T14I is designed to excel in demanding environments. Its average power handling capacity of ≤16kW, extendable to ≤20kW with additional blowers, meets the needs of even the most power-intensive broadcasts.
Seamless Integration
Featuring EIA 1-5/8", EIA 3-1/8", and EIA 6-1/8" input and output connectors, it integrates smoothly into existing setups. Its optimal design minimizes insertion loss and maximizes return loss, ensuring efficient signal transmission.
| MPN | FT3T14I |
|---|---|
| Brand | Dielectric |
| Product Condition | New |
| Availability | Out of Stock |
