Optimized For High-Output Installed Sound Applications
The EAW MK5366i WHITE is a premium 800W passive 2-way full-range loudspeaker built for professional sound reinforcement in a wide range of installed environments. Designed as part of the MK5300i Series, this model is perfect for main PA use in smaller venues like auditoriums, theaters, houses of worship, or meeting spaces, while also providing exceptional results in larger distributed systems across stadiums, arenas, and themed entertainment complexes. With powerful output and consistent coverage, the MK5366i WHITE is engineered for environments demanding precise audio reproduction and long-term reliability.
High-Fidelity Sound With Consistent Directivity
Featuring a 15-inch low-frequency transducer and a custom 3-inch voice coil, 1.4-inch exit compression driver, the MK5366i WHITE delivers smooth, full-range sound reproduction. This model incorporates a 60° x 60° horn designed to maintain directivity throughout the HF passband, ensuring even dispersion and intelligibility across the coverage area. The speaker's large-format HF horn is carefully matched to the enclosure size, providing seamless integration between the drivers and minimizing pattern distortion often found in smaller two-way systems.
Versatile Coverage And Scalable System Design
The MK5366i WHITE is part of a flexible family of models offering multiple horn patterns. All MK5300i Series loudspeakers are carefully voiced to sound alike, enabling mixed horn patterns to be used throughout an installation without compromising tonal consistency. This is ideal for system designs requiring varied dispersion characteristics in different zones while maintaining uniform sonic performance. The enclosure shares height with EAW's MK2300i and SBK Series subwoofers, enabling cohesive, vertically aligned array configurations when desired.
Powerful Output For Demanding Environments
With an operating range from 48 Hz to 17 kHz, this loudspeaker handles a wide range of material with clarity and control. It is capable of reaching peak SPL levels of 133 dB, with a maximum SPL of 139 dB and an axial sensitivity of 98 dB (LF/HF). The MK5366i WHITE is engineered to deliver clean, high-fidelity output at levels that rival much larger enclosures, making it an ideal solution for high-performance applications requiring extended bandwidth and punch.
Flexible Amplification And Signal Processing Options
The MK5366i WHITE supports both single-amp and bi-amp operating modes, giving system integrators the flexibility to tailor system performance to the venue's needs. For installations using external DSP, EAW's beamwidth-matching crossover and filter design maintain smooth power response across the crossover region, minimizing common anomalies in two-way speaker systems. This approach ensures consistent sound quality on- and off-axis, improving intelligibility and coherence across the listening area.
Durable Construction For Indoor And Outdoor Installations
Constructed with exterior-grade Baltic birch plywood and finished in wear-resistant textured white paint, the MK5366i WHITE is built to handle the rigors of permanent installation. The front grille is a powder-coated perforated steel design, protecting the internal components while preserving acoustic transparency. The IP56 rating confirms its ability to resist dust and water intrusion, making it suitable for outdoor environments where weather resistance is critical.
System Integration For Custom Configurations
Thanks to its uniform height and shared design language with other EAW installation products, the MK5366i WHITE integrates smoothly into larger system deployments. Whether used with companion MK models or SBK subwoofers, the result is a unified visual and sonic design that scales easily from small rooms to large-scale installations.
