EAW MK8126i 8'' Passive Speaker

Compact loudspeaker with full-range clarity and coverage
The EAW MK8126i WHITE is a passive 2-way installation loudspeaker built to outperform traditional compact two-way systems, even while occupying less physical space. Designed for demanding permanent installations in theaters, clubs, houses of worship, and multi-zone commercial spaces, the MK8126i delivers clear, articulate sound with consistent coverage across its 120° x 60° dispersion field. This loudspeaker features an 8-inch low-frequency driver paired with a 1-inch exit, 1.5-inch voice coil compression driver mounted on a custom constant directivity horn that extends pattern control deeper into the midrange.

Horn design for consistent off-axis response
Unlike typical compact systems, the MK8126i uses a significantly larger HF horn that precisely overlaps the woofer’s pattern in the crossover region. This eliminates common beamwidth mismatches that create off-axis dead zones, providing more uniform sound throughout the listening space. Whether mounted horizontally or vertically, the user-rotatable horn maintains a consistent dispersion pattern, ensuring sonic accuracy and intelligibility in any orientation.

Advanced crossover network with beamwidth matching
At the heart of the MK8126i is a complex internal passive crossover network that does more than divide frequencies. It applies asymmetrical filters to optimize integration between the drivers while also performing essential equalization functions. This beamwidth-matched crossover point allows a seamless transition between the LF and HF drivers, ensuring the speaker maintains coherent phase and frequency response across its entire operating range of 65Hz to 19kHz.

High SPL performance from a compact footprint
Don’t let the size fool you—this speaker is built to deliver serious output. With a maximum SPL of 130 dB (12 dB crest factor) and 124 dB (6 dB crest factor), the MK8126i handles high-energy program material with ease, all while maintaining clarity and detail. With an 8Ω nominal impedance and 300W power handling, it works efficiently with standard installation amplifiers, making system integration straightforward and reliable.

Installation-friendly and visually discreet
With dimensions of just 19.75 x 11.75 x 11.03 inches and weighing only 30 lbs, the MK8126i WHITE is easy to mount in both horizontal and vertical orientations. It features a durable Baltic birch enclosure finished in textured white paint for visual sensitivity in architecturally demanding spaces. The included U-bracket simplifies wall and ceiling mounting, and the rotatable horn ensures consistent directivity regardless of orientation.

Built for long-term durability in fixed installs
This model is designed for long-term reliability, featuring a rugged plywood enclosure, internal passive components optimized for full-range clarity, and flexible input connections via dual NL4 connectors and a barrier strip. The MK8126i’s passive configuration reduces system complexity and makes it an ideal choice for fixed installation projects where consistency, clarity, and aesthetics are top priorities.
