EAW MKD1264-WP

Full-range loudspeaker built for professional fixed installations
The EAW MKD1264-WP WHITE is a high-output 1200W passive 2-way installation loudspeaker engineered for clarity, control, and reliability in performance-critical environments. From stadiums and theaters to nightclubs and churches, this weather-protected speaker delivers full-bandwidth sound with exceptional pattern control. Featuring dual 12-inch low-frequency drivers and a 2-inch exit, 4-inch voice coil compression driver, the MKD1264-WP WHITE ensures robust low-end performance and crystal-clear highs, all within a compact footprint suited for permanent indoor or outdoor installations.

Precision coverage with 60° x 45° beamwidth
Designed to focus energy exactly where it's needed, the MKD1264-WP WHITE offers a nominal dispersion pattern of 60° horizontal by 45° vertical. This tightly defined coverage is ideal for rooms with reflective surfaces or spaces requiring accurate targeting to minimize bleed and maintain intelligibility. Whether installed in an acoustically challenging arena or a reverberant hall, the speaker’s beamwidth-matched crossover ensures smooth summation across the frequency spectrum, resulting in phase-coherent sound from top to bottom.

QX-inspired driver layout for wideband clarity
Borrowing engineering principles from EAW’s QX series, the MKD1264-WP WHITE places its high-frequency driver in a central, rotatable horn, surrounded by dual low-frequency transducers. This layout ensures time alignment and acoustic coherence across the frequency range, while also allowing the horn to be rotated to suit vertical or horizontal deployment. The speaker achieves an operating range of 50 Hz to 20 kHz and produces a max SPL of 145 dB, easily handling high-energy environments without distortion.

Flexible integration and rigging options
The MKD1264-WP WHITE can be deployed in either passive or bi-amplified modes, giving system integrators control over how power and DSP are distributed. With 12 M10 threaded mounting points, the cabinet supports secure rigging via eyebolts or optional U-brackets, making it easy to install in horizontal or vertical orientations. A terminal block input ensures a reliable connection, and the speaker integrates seamlessly into both distributed systems and standalone main speaker configurations.

Weather-protected enclosure for indoor and outdoor use
This model is built with a durable Baltic birch plywood cabinet finished in wear-resistant white paint, designed to blend into visually sensitive spaces while resisting environmental wear. The IP56 weather rating provides assurance for use in partially or fully exposed installations. With a gently curved grille and neutral color, the MKD1264-WP WHITE meets architectural demands without compromising audio performance, making it ideal for installations where both form and function matter.

Consistent high-fidelity performance across applications
With 93 dB sensitivity and a flat SPL of 139 dB (6 dB crest factor), the MKD1264-WP WHITE ensures consistent output with excellent fidelity. Its combination of controlled coverage, wide frequency response, and QX-inspired coherence makes it suitable for FOH applications, delay zones, or multi-zone distributed systems. Whether reinforcing speech, music, or multimedia playback, this loudspeaker delivers articulate, balanced audio that scales with the demands of the venue.
