EAW MKD1294-WP Loudspeaker (White)

High-performance loudspeaker for installed sound systems
The EAW MKD1294-WP WHITE is a 1200W passive 2-way installation loudspeaker designed for demanding professional environments where high-output performance, consistent pattern control, and pristine audio fidelity are non-negotiable. With dual 12-inch low-frequency transducers and a 2-inch exit, 4-inch voice coil compression driver, this speaker delivers full-range, high-impact sound reproduction. Its weather-protected white enclosure makes it suitable for both indoor and outdoor use in visually sensitive applications, from sports venues and concert halls to houses of worship and performance spaces.

Built to meet real-world installation demands
Engineered for modern installations, the MKD1294-WP WHITE merges compact form with rugged construction. The Baltic birch enclosure is built for durability in permanent installs while offering a sleek aesthetic that blends seamlessly into architectural environments. With a nominal beamwidth of 90° horizontal by 45° vertical, this loudspeaker delivers precise, broadband pattern control that ensures even coverage across large spaces, minimizing acoustic dead zones and maximizing audience engagement.

Acoustically advanced transducer and horn system
At the core of the MKD1294-WP WHITE is a spaced low-frequency driver layout centered around a large-format rotatable horn, derived from EAW’s QX Series. This design enables the system to extend low-frequency response without sacrificing mid/high clarity. Beamwidth-matched crossover technology ensures the LF and HF sections integrate smoothly, allowing for consistent tonal balance throughout the speaker’s 50Hz to 20kHz operating range.

High output with system integration flexibility
Capable of producing a maximum SPL of 145 dB and a flat SPL of 139 dB (6 dB crest factor), the MKD1294-WP WHITE handles everything from subtle background audio to intense live sound reinforcement. The speaker supports both passive and bi-amplified operation, giving system designers flexibility to configure for different performance and control requirements. Input is managed via a secure terminal block, and system optimization is available using external DSP platforms.

Weather-protected enclosure for outdoor installations
With an IP56 rating, the MKD1294-WP WHITE is prepared for challenging environmental conditions. Whether deployed in an open-air amphitheater, stadium, or covered outdoor area, this loudspeaker withstands dust and water exposure while maintaining consistent audio performance. Its white finish and gently curved grille design allow for discreet placement in architecturally sensitive areas, ensuring that aesthetics do not come at the cost of audio quality.

Easy rigging and mounting options
For installation convenience, the MKD1294-WP WHITE includes 12 M10 mounting points, compatible with U-brackets, eyebolts, and custom rigging hardware. Whether suspended horizontally or mounted vertically, this speaker adapts to nearly any configuration. Its 32 x 22.7 x 20.6-inch footprint and 104 lb weight make it manageable for integration into both large-scale systems and tighter installations where precision is key.
