EAW QX594i-WP 3-Way Loudspeaker (White)

High output three-way loudspeaker built for demanding installs
The EAW QX594i-WP WHITE is a weather-protected, high-performance 3-way loudspeaker designed for permanent installations in venues where long-throw capability, even coverage, and tonal fidelity are critical. With a bi-amplified design and high-output architecture, this loudspeaker delivers consistent broadband pattern control, even in acoustically difficult environments like cathedrals, stadiums, and large public venues. Its compact, symmetrical enclosure is engineered for seamless integration and point-source performance across the full frequency range.

Purpose-built for wide coverage and throw distance
The QX594i-WP WHITE uses a constant directivity horn with a 90° horizontal by 45° vertical coverage pattern, providing predictable dispersion over long distances. A coaxial mid/high compression driver sits at the heart of the enclosure, delivering precise output with excellent phase coherence. Whether installed in a high-energy music venue or a reverberant public space, this speaker offers control where it matters most—across the full listening area.

Symmetrical driver configuration for point-source accuracy
EAW’s Phase Aligned™ configuration uses four 12-inch low-frequency drivers arranged in vertical and horizontal pairs around the coaxial MF/HF section. This setup ensures that the entire frequency spectrum behaves as if it's coming from a single origin point. The result is a coherent sound field that maintains clarity and consistency both horizontally and vertically, with reduced lobing and phase issues common in offset driver layouts.

Built for harsh environments with installation-ready construction
As a WP (weather-protected) model, the QX594i-WP WHITE is prepared for outdoor and indoor use where environmental protection is required. The enclosure is made of exterior-grade Baltic Birch plywood and coated with a wear-resistant white finish. A powder-coated steel grille further protects the drivers while preserving acoustic transparency. With multiple mounting points, this loudspeaker is ready for rigging in fixed installations across arenas, houses of worship, and large performance venues.

Optimized for integration with advanced DSP and amplification
The QX594i-WP is designed to pair with EAW digital processors and recommended amplification to achieve optimal system performance. When deployed with the appropriate presets, users benefit from tighter frequency response control, extended low-end handling, and protection circuitry tailored to the loudspeaker’s capabilities.
