High-Voltage Transformer Built for RF Sampling and Isolation Applications
The Kintronic Labs 923-0004-001 TCT-1-XHV is a precision-engineered high-voltage RF transformer designed for demanding broadcast and transmission environments. Rated at 0.50VA and capable of handling up to 42.4KVRMS, this unit is ideal for applications requiring signal sampling, transmission line monitoring, or galvanic isolation in high-voltage AM antenna systems. It provides stable, reliable signal transfer with minimal insertion loss, even under extreme RF conditions.

Optimized for AM Radio and High-Voltage RF Transmission Systems
This transformer is specifically designed for high-voltage AM broadcast use where accurate signal sampling or coupling is needed. With its 0.50VA rating, it is built to deliver consistent performance in transmission lines carrying high power while ensuring electrical isolation and maintaining RF signal integrity. Its configuration supports both safety and precision in high-voltage monitoring setups.

Engineered for High-Voltage Isolation Up to 42.4KVRMS
The TCT-1-XHV model supports a peak isolation capacity of 42.4KVRMS, making it suitable for use in environments where equipment must interface with high-power RF circuits without direct electrical connection. This level of isolation helps protect sensitive gear downstream and ensures compliance with broadcast engineering standards for safety and interference reduction.

Compact and Durable Construction for Field and Facility Installation
The transformer is housed in a compact, rugged design that supports installation within transmitter facilities, tuning units, or remote RF enclosures. Its build quality ensures long-term reliability in harsh RF environments, withstanding mechanical vibration, temperature variations, and continuous signal exposure. The unit’s design supports integration into both new builds and existing infrastructure with minimal modification.

Ideal for Precision Signal Sampling and RF Monitoring Tasks
Whether it’s being used in impedance measurement systems, transmission line sampling points, or RF detection circuits, the TCT-1-XHV delivers precise signal handling and consistent electrical performance. Its characteristics make it especially useful in AM directional antenna systems and transmitter monitoring setups, where maintaining signal clarity and safety is essential.

Tested to Meet Rigorous Industry Standards for Performance and Safety
Kintronic Labs manufactures each unit to meet stringent RF industry quality control requirements. Every transformer is tested for voltage handling, phase response, and mechanical reliability, ensuring that each unit provides stable performance for long-term service in professional broadcast applications.
