Rohn 45GSR90R130 130FT Guyed Tower System

130-Foot Guyed Tower System Designed for 90 MPH Wind Performance
The ROHN 45GSR90R130 is a complete 130-foot guyed tower package built to support antenna systems in moderate wind environments. Rated for 90 MPH (3-second gusts), this tower is engineered for commercial, amateur, public safety, and broadband applications requiring dependable height and structural support. Whether you're running a rural WISP, building a long-range radio network, or installing a surveillance relay, this tower delivers the strength and vertical coverage you need.

Heavy-Duty Solid Steel Rod Legs Maximize Structural Integrity
This model uses solid 1.25" round steel legs, which provide greater compressive strength and durability than hollow tube designs. These solid legs handle heavy equipment and resist long-term stress from guy wire tension, wind load, and environmental exposure. The ROHN 45GSR90R130 is built to endure the daily strain of critical infrastructure operation with minimal deflection or flexing.

Zig-Zag Solid Rod Bracing Enhances Wind Resistance
Engineered with a continuous solid-rod zig-zag bracing system across its 18" triangular face, the tower maintains balance and alignment even during wind gusts or uneven loading. This bracing system reinforces the tower against lateral sway and torque, allowing antennas and dishes to hold their aimed direction without drift or vibration, helping to maintain consistent signal quality.

Modular Sections and Double-Bolted Connections Simplify Installation
The tower is assembled from 10-foot modular sections, each connected with secure double-bolted joints to maximize rigidity. This modular format enables easier transportation and staging, especially in rural or difficult-to-access locations. The double-bolt design ensures each section maintains firm alignment and minimizes vibration across the structure.

Fully Galvanized After Fabrication for Corrosion Protection
Every piece of the tower is hot-dip galvanized after fabrication, forming a weather-resistant shield against rust and corrosion. This coating extends service life significantly and reduces ongoing maintenance, particularly in moisture-rich, salt-air, or snowy environments. You can expect reliable performance season after season, year after year.

Ready for Communication, Radio, and Surveillance Networks
With its height, load capacity, and wind rating, the ROHN 45GSR90R130 is a versatile tower suited for use in two-way radio, broadband transmission, amateur radio, and microwave backhaul systems. The strong steel design supports heavy-duty antennas while offering flexibility in mounting options across multiple sectors and use cases.

Supports Multiple Foundation Options for Field Versatility
The tower can be installed using a base plate with anchor bolts, a hinged base for tilt-up construction, or a cast-in-place foundation. These options allow the system to be deployed in a wide variety of terrain and jobsite conditions while maintaining consistent performance and safety.
